Ratings
Notes: Product with spring, its usable range of operating part is within one third of the whole spring length from the front end of spring.
Specifications
Operating Characteristics
Appearance and Dimension
Cabling Attention
The switch bodies are filled with resin for sealing purposes. To avoid stressing the cable and switch body, fasten the switch at 5 cm or farther away from the switch body, should the wire be bent, the bending radius shall be at least 45mm.
Quantity Mounted Using Attention
A maximum of six switches may be mounted together as a switch bank.During the installation,the convex part of the switch back.The mounting panel shall be 6mm or thicker.
Contact Form
The switch bodies are filled with resin for sealing purposes. To avoid stressing the cable and switch body, fasten the switch at 5 cm or farther away from the switch body, should the wire be bent, the bending radius shall be at least 45mm.
Mounting Holes
Mount the switch body to a rigid mounting panel using two M5 screws.
Installation Attention
The service life and accuracy of switches will be effected by the shape of actuator operation frequency & over travel. So the angular of the fixing level should be about 30°, the surface finish of the fixing level should be over, the hardness is from HV400~500.When installing, the position of the concave part should be above the standard panel.
Recommended tightening torque according to the follwing form.
